134 EKI-7710 Series User Manual
Packet Info Tx Packets
Counter
4
words
64 bits HEX 0x2000 ~
0x207C
38193 ~
38317
Tx Packets
Ex: port 1 Tx Packet
Amount = 11223344
Received MODBUS
response: 0xAB4130
Word 0 = 0x0000
Word 1 = 0x0000
Word 2 = 0x00AB
Word 3 = 0x4130
Port 1 Tx
Packets
4
words
64 bits HEX 0x2000 38193
Port 2 Tx
Packets
4
words
64 bits HEX 0x2004 38197
Port 3 Tx
Packets
4
words
64 bits HEX 0x2008 38201
Port 4 Tx
Packets
4
words
64 bits HEX 0x200C 38205
Port 5 Tx
Packets
4
words
64 bits HEX 0x2010 38209
Port 6 Tx
Packets
4
words
64 bits HEX 0x2014 38213
Port 7 Tx
Packets
4
words
64 bits HEX 0x2018 38217
Port 8 Tx
Packets
4
words
64 bits HEX 0x201C 38221
Port 9 Tx
Packets
4
words
64 bits HEX 0x2020 38225
Port 10 Tx
Packets
4
words
64 bits HEX 0x2024 38229
Port 11 Tx
Packets
4
words
64 bits HEX 0x2028 38233
Port 12 Tx
Packets
4
words
64 bits HEX 0x202C 38237
Port 13 Tx
Packets
4
words
64 bits HEX 0x2030 38241
Port 14 Tx
Packets
4
words
64 bits HEX 0x2034 38245
Port 15 Tx
Packets
4
words
64 bits HEX 0x2038 38249
Catelog Name Data Type Interpretation Address
Offset (Hex)
Address
3X
Description
