136 EKI-7710 Series User Manual
Packet Info Rx Packets
Counter
4
words
64 bits HEX 0x2100
~0x217C
38449 ~
38573
Rx Packets
Ex: port 1 Rx Packet
Amount = 11223344
Received MODBUS
response: 0xAB4130
Word 0 = 0x0000
Word 1 = 0x0000
Word 2 = 0x00AB
Word 3 = 0x4130
Port 1 Rx
Packets
4
words
64 bits HEX 0x2100 38449
Port 2 Rx
Packets
4
words
64 bits HEX 0x2104 38453
Port 3 Rx
Packets
4
words
64 bits HEX 0x2108 38457
Port 4 Rx
Packets
4
words
64 bits HEX 0x210C 38461
Port 5 Rx
Packets
4
words
64 bits HEX 0x2110 38465
Port 6 Rx
Packets
4
words
64 bits HEX 0x2114 38469
Port 7 Rx
Packets
4
words
64 bits HEX 0x2118 38473
Port 8 Rx
Packets
4
words
64 bits HEX 0x211C 38477
Port 9 Rx
Packets
4
words
64 bits HEX 0x2120 38481
Port 10 Rx
Packets
4
words
64 bits HEX 0x2124 38485
Port 11 Rx
Packets
4
words
64 bits HEX 0x2128 38489
Port 12 Rx
Packets
4
words
64 bits HEX 0x212C 38493
Port 13 Rx
Packets
4
words
64 bits HEX 0x2130 38497
Port 14 Rx
Packets
4
words
64 bits HEX 0x2134 38501
Port 15 Rx
Packets
4
words
64 bits HEX 0x2138 38505
Catelog Name Data Type Interpretation Address
Offset (Hex)
Address
3X
Description
