Advantech EKI-7710E-2C - Page 151

138 EKI-7710 Series User Manual
Packet Info Tx Error Pack-
ets Counter
2
words
32 bits HEX 0x2200 ~
0x223E
38705 ~
38767
Tx Error Packets
Ex: port 1 Tx Packet
Amount = 11223344
Received MODBUS
response: 0xAB4130
Word 0 = 0x00AB
Word 1 = 0x4130
Port 1 Tx Error
Packets
2
words
32 bits HEX 0x2200 38705
Port 2 Tx Error
Packets
2
words
32 bits HEX 0x2202 38707
Port 3 Tx Error
Packets
2
words
32 bits HEX 0x2204 38709
Port 4 Tx Error
Packets
2
words
32 bits HEX 0x2206 38711
Port 5 Tx Error
Packets
2
words
32 bits HEX 0x2208 38713
Port 6 Tx Error
Packets
2
words
32 bits HEX 0x220A 38715
Port 7 Tx Error
Packets
2
words
32 bits HEX 0x220C 38717
Port 8 Tx Error
Packets
2
words
32 bits HEX 0x220E 38719
Port 9 Tx Error
Packets
2
words
32 bits HEX 0x2210 38721
Port 10 Tx
Error Packets
2
words
32 bits HEX 0x2212 38723
Port 11 Tx
Error Packets
2
words
32 bits HEX 0x2214 38725
Port 12 Tx
Error Packets
2
words
32 bits HEX 0x2216 38727
Packet Info Port 13 Tx
Error Packets
2
words
32 bits HEX 0x2218 38729
Port 14 Tx
Error Packets
2
words
32 bits HEX 0x221A 38731
Port 15 Tx
Error Packets
2
words
32 bits HEX 0x221C 38733
Port 16 Tx
Error Packets
2
words
32 bits HEX 0x221E 38735
Port 17 Tx
Error Packets
2
words
32 bits HEX 0x2220 38737
Port 18 Tx
Error Packets
2
words
32 bits HEX 0x2222 38739
Port 19 Tx
Error Packets
2
words
32 bits HEX 0x2224 38741
Port 20 Tx
Error Packets
2
words
32 bits HEX 0x2226 38743
Port 21 Tx
Error Packets
2
words
32 bits HEX 0x2228 38745
Port 22 Tx
Error Packets
2
words
32 bits HEX 0x222A 38747
Port 23 Tx
Error Packets
2
words
32 bits HEX 0x222C 38749
Port 24 Tx
Error Packets
2
words
32 bits HEX 0x222E 38751
Port 25 Tx
Error Packets
2
words
32 bits HEX 0x2230 38753
Port 26 Tx
Error Packets
2
words
32 bits HEX 0x2232 38755
Catelog Name Data Type Interpretation Address
Offset (Hex)
Address
3X
Description
