EKI-7710 Series User Manual 51
The ensuing table for Port VLAN Status settings are informational only: Port, Inter-
face VLAN Mode, PVID, Accept Frame Type and Ingress Filtering.
4.5.4.3 Port to VLAN
The Port to VLAN page allows you to add a port to a VLAN and select the related
parameters.
Accepted Type Click the radio button to specify which frames to forward.
Tag Only discards any untagged or priority tagged frames.
Untag Only discards any tagged frames.
All accepts all untagged and tagged frames.
Whichever you select, VLAN tagged frames are forwarded in accor-
dance with the IEEE 802.1Q VLAN standard. The default is All.
Ingress Filtering Click the radio button to specify how you want the port to handle
tagged frames. If you enable Ingress Filtering, a tagged frame will be
discarded if this port is not a member of the VLAN identified by the
VLAN ID in the tag. If you select Disabled, all tagged frames will be
accepted. The default is Disabled.
Apply Click Apply to save the values and update the screen.
Item Description
