AGFA CR 30-X - Page 347

DRAWER CASSETTE UNIT
TYPE 5175/100/110
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
=Assembly
D =Standard part. For order please refer to the separate spare parts list for standard parts "DD+DIS011.93M"
* =No wearing part.
Pos. Nr.
Item no.
Pos. no.
Teile-Nr.
Part No.
Nr. de Ref.
Benennung
Description
Denomination
CM+9517552003
1
KASSETTENÖFFNER
CASSETTE OPENER UNIT
SYSTÈME D'OUVERTURE CASSETTE
CM+9516050060
2
ANTISTATIKBÜRSTE
ANTISTATIC BRUSH - (CASSETTE UNIT ENTRY)
BROSSE ANTISTATIQUE
CM+9048614170
3
CHIP READER
CHIP READER
CHIP READER
CM+9517590500
4
ZAHNRIEMEN F. KASSETTENEINHEIT
TOOTHED BELTS FOR CASSETTE UNIT
POULIE A COURROIE POUR MODULE CASSETTE
CM+9517545190
5
MOTOR KASSETTENÖFFNER - (M3)
MOTOR CASSETTE OPENER - (M3)
MOTEUR SYSTEME D'OUVERTURE CASSETTE - (M3)
CM+9517590403
6
KASSETTENAUFNAHME
CASSETTE FIXATION UNIT
LONGEMENT DE CASSETTE
CM+9517590600
7
MICROSCHALTER
CASSETTE EDGE SENSOR
MICRORUPTEUR
CM+9517552302
8
IP HANDLING BOARD
IP HANDLING BOARD
IP HANDLING BOARD
CM+9517558301
9
CASSETTE FIXATION STEEL BAND
CASSETTE FIXATION STEEL BAND
CASSETTE FIXATION STEEL BAND
CM+9517558100
10
MOTOR KASSETTENKLEMMER - (M1)
MOTOR CASSETTE FIXING - (M1)
MOTEUR FIXAGE DE CASSETTES - (M1)
CM+9517556002
11
KASSETTENENTRIEGLER
CASSETTE UNLOCKING UNIT
CASSETTE DEVERROUILLAGE
CM+9517514100
12
BÜRSTE KOMPL. GROSS (BUCHSE Ø4MM)
BRUSH COMPLETE LARGE (BUSHING Ø4MM)
BROSSE COMPLET GRAND (DOUILLE Ø4MM)
CM+9517514110
13
BÜRSTE KOMPL. KLEIN (BUCHSE Ø3MM)
BRUSH COMPLETE SMALL (BUSHING Ø3MM)
BROSSE COMPLET PETIT (DOUILLE Ø3MM)
DD+DIS325.06M
Spare Parts List
Edition 1, Revision 3 Chapter 5 / 15CR 30-X
01-2009
Agfa Company Confidential
