Screw M 4 x 12 (DIN912)
(Mounting of covers)
3 x
2 x 0.5 A 5 x 1.0 A
2 x 2.0 A 3 x 2.5 A
3 x 3.5 A 2 x 5.0 A
2 x 7.0 A
Micro fuses
2 x 14 (DIN7)
(Mounting of gears in transport unit)
2 x
M2 (DIN 439)
(Mounting of cassette edge sensor)
2 x
Screw M 4 x 8 (DIN912)
(Mounting of cassette unit)
4 x
M2x10 (DIN912)
(Mounting of cassette edge sensor)
2 x
Special screw M3
(Mounting of permanent magnets
at drawer unit)
1 x
Spring washer D = 2,2 mm (DIN127)
(Mounting of cassette edge sensor)
2 x
Spring washer D = 4,3 mm (DIN127)
(Mounting of cassette unit)
3 x
Washer d = 4,3 mm (DIN9021)
(Mounting of front cover)
4 x
DD+DIS325.06M
Spare Parts List
Edition 1, Revision 3 Chapter 5 / 16CR 30-X
TYPE 5175/100/110
01-2009
SMALL PARTS AND TOOLS
