A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 141 / 812
1.10.3.9. HS TIMER 1 INTERVAL VALUE LO REGISTER
Offset:0x34
Register Name: HS_TMR1_INTV_LO_REG
Bit
Read/
Write
Default/He
x
Description
31:0
R/W
x
HS_TMR1_INTV_VALUE_LO.
High Speed Timer 1 Interval Value [31:0].
1.10.3.10. HS TIMER 1 INTERVAL VALUE HI REGISTER
Offset:0x38
Register Name: HS_TMR1_INTV_HI_REG
Bit
Read/
Write
Default/He
x
Description
31:24
/
/
/
23:0
R/W
x
HS_TMR1_INTV_VALUE_HI.
High Speed Timer 1 Interval Value [55:32].
Note: the interval value register is a 56-bit register. When read or write the interval value, the Lo
register should be read or written first. And the Hi register should be written after the Lo register.
1.10.3.11. HS TIMER 1 CURRENT VALUE LO REGISTER
Offset:0x3C
Register Name: HS_TMR1_CURNT_LO_REG
Bit
Read/
Write
Default/He
x
Description
31:0
R/W
x
HS_TMR1_CUR_VALUE_LO.
High Speed Timer 1 Current Value [31:0].
1.10.3.12. HS TIMER 1 CURRENT VALUE HI REGISTER
Offset:0x40
Register Name: HS_TMR1_CURNT_HI_REG
Bit
Read/
Write
Default/He
x
Description
31:24
/
/
/
23:0
R/W
x
HS_TMR1_CUR_VALUE_HI.
High Speed Timer 1 Current Value [55:32].
Note:
