A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 334 / 812
Offset: 0xC8
Register Name: MP_CKMAX_REG
Bit
Read/W
rite
Default/
Hex
Description
Red
15:8
R/W
0
CKMAX_G
Green
7:0
R/W
0
CKMAX_B
Blue
3.1.4.25. FILL COLOR OF ROP OUTPUT SETTING REGISTER
Offset: 0xCC
Register Name: MP_ROPOUTFILLCOLOR_REG
Bit
Read/W
rite
Default/
Hex
Description
31:24
R/W
0
Alpha
23:16
R/W
0
Red
15:8
R/W
0
Green
7:0
R/W
0
Blue
3.1.4.26. COLOR SPACE CONVERTER 2 CONTROL REGISTER
Offset: 0xD0
Register Name: MP_CSC2CTL_REG
Bit
Read/W
rite
Default/
Hex
Description
31:1
/
/
/
0
R/W
0
CSC2_EN
Enable control
0:
Disable color space function, ignore the control setting, and the
data flow will by-pass the module.
1:
Enable color space converting function.
