Offset: 0x18
Register Name: TWI_SRST
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:1
/
/
/
0
R/W
0
SOFT_RST
Soft Reset
Write ‘1’ to this bit to reset the TWI and clear to ‘0’ when
completing Soft Reset operation.
6.2.4.7. TWI ENHANCE FEATURE REGISTER
Offset: 0x1C
Register Name: TWI_EFR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:2
/
/
/
0:1
R/W
0
DBN
Data Byte number follow Read Command Control
No Data Byte to be wrote after read command
Only 1 byte data to be wrote after read command
2 bytes data can be wrote after read command
3 bytes data can be wrote after read command
6.2.4.8. TWI LINE CONTROL REGISTER
Offset: 0x20
Register Name: TWI_LCR
Default Value: 0x0000_003a
Bit
Read/Write
Default
Description
31:6
/
/
/
5
R
1
SCL_STATE
Current state of TWI_SCL
0 – low
1 - high
4
R
1
SDA_STATE
Current state of TWI_SDA
