A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 752 / 812
Offset: 0x20
Register Name: TSC_TSFMUXR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
TSF0 Input Multiplex Control
0x0 –Data from TSG
0x1 –Data from TS IN Port0
0x2 –Data from TS IN Port1
Others – Reserved
6.13.4.6. TSC PORT OUTPUT MULTIPLEX CONTROL REGISTER
Offset: 0x28
Register Name: TSC_TSFMUXR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:4
/
/
/
3:0
R/W
0x0
TSPortOutputMuxCtrl
TS Port Output Multiplex Control
0x0 – Data from TSG
0x1 –Data from TS IN Port0
0x2 –Data from TS IN Port1
Others – Reserved
6.13.4.7. TSG CONTROL AND STATUS REGISTER
Offset: TSG+0x00
Register Name: TSG_CSR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:26
/
/
/
25:24
R
0
TSGSts
Status for TS Generator
0: IDLE state
1: Running state
2: PAUSE state
Others: Reserved
