6.13.4.28. TSF CHANNEL STATUS REGISTER
Offset: TSF+0x44
Register Name: TSF_CSTAR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:0
/
/
/
6.13.4.29. TSF CHANNEL CW INDEX REGISTER
Offset: TSF+0x48
Register Name: TSF_CCWIR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:3
/
/
/
2:0
R/W
0x0
CWIND
Related Control Word Index
Index to the control word used by this channel when
Descramble Enable of this channel enable.
This value is useless when the corresponding Descramble
Enable is ‘0’.
6.13.4.30. TSF CHANNEL PID REGISTER
Offset: TSF+0x4c
Register Name: TSF_CPIDR
Default Value: 0x1fff_0000
Bit
Read/Write
Default
Description
31:16
R/W
0x1fff
PIDMSK
Filter PID Mask for Channel
15:0
R/W
0x0
PIDVAL
Filter PID value for Channel
