Transmission Argo Service Manual
TR-44
49. If the old bushing(s) was/were replaced with new, press a burnishing tool through
the Oilite Bushing of the Reverse Idler.
Photo TR-159 & 160
50. Slip the Reverse Idler on to the Dowel Pin making sure that the chamfer side is
facing down. Photo TR-161, 162 & 163
TR-158
TR-159
TR-160
TR-161
TR-162 TR-163
