Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Argo Service Manual Transmission
TR-45
51. While one hand holds the top of the Shifter Assembly, Use the other to shift the
Lever through all gates. Check that all shift smoothly. Photo TR-164
52. Spin the entire assembly at the Output Shaft to check for any tight spots or unusual
noises. Photo TR-165
53. Apply Black 598 LOCTITE RTV Silicon Gasket Maker to the bottom half of the
Housing. Photo TR-166
54. Install the Cover Gasket to the sealing edge of the Housing. Photo TR-167
55. Apply the same gasket compound to the lower edge of the Side Cover as well.
Photo TR-168 (following page)
56. Install the Cover to the Housing and press to fit. Photo TR-169,170 & 171 When
applying pressure to the cover at the press, use a soft faced mallet to tap the top end
of the cover at the same time to ensure that the cover is not installed crooked. Photo
TR-172 & 173 (following page)
TR-164 TR-165
TR-166 TR-167
