TR-17A
Argo Service Manual Transmission
Assembling the Differential
1. Install all 105-03 Oilite Bushings into both 34-122 cage and 34-124 Gear Plate.
Photo TR-58 & 59
TR-58
TR-59
2. Blow all foreign debris from the Cage and Gear Plate.
5. Install the 101-15 Bearing into both Cage and Gear plate. Photo TR-60 & 61
6. Wipe the 34-98 Output Shaft free of debris with a lint free rag. Install this Output
Shaft into the Aluminum Cage. Photo TR-62 & 63 See Note following page.
TR-60
TR-61
TR-62 TR-63
To Next Page
