Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
TR-29A
Argo Service Manual Transmission
TR-120 TR-121
TR-122
25. Place the transmission into the neutral position. Photo TR-123
TR-123
26. Secure the Hi/Lo Shift Fork to the Shift Shaft using a 104-39 Spring Pin.
Photo TR-124
TR-124 TR-125
27. Install a 106-03 Retaining Ring to the top groove of the 34-101 Left Transmission
Housing at the output shaft opening, and a 106-05 Retaining ring at the input shaft
opening Photo TR-125
28. Place a 114-01 shim to the top of the 106-03 Retaining Ring.
To Next Page
