Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
TR-32A
Transmission Argo Service Manual
TR-136
38. Install a 101-05 Bearing to the Output Shaft. Photo TR-136 & 137
TR-137
39. Repeat Steps 36 through 38 for the other Output Shaft.
40. Using the Output Shaft puller, pull each of the Output Shafts. Install a 114-04 Shim
under the 107-02 Retaining Ring at the Output Shaft on the Left Side Housing. Install
a 114-05 Shim under the 107-02 Retaining Ring at the Output Shaft on the Right
Hand Side Housing. Photo TR-138, 139 & 140
IMPORIMPOR
IMPORIMPOR
IMPOR
TT
TT
T
ANTANT
ANTANT
ANT
Ensure that all retaining rings are seated properly
TR-138 TR-139
TR-140
