Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
TR-35A
Argo Service Manual Transmission
1. Transmissions built from A5883: Locate the 34-130 Input Shaft and install the first
half of the 107-14 Retaining Ring to the machined groove at the High Gear Pinion
location. Photo 1 & 2
2. Interlock the second half of the 107-14 Retaining Ring into the previously installed
one. Photo 3 At the opposite side, squeeze the retaining ring assembly together to lock
and seat securely into the machined groove. Photo 4 & 5
1 2
3
4
To Next Page
