TR-36A
Transmission Argo Service Manual
4. Locate the 108-85 Retaining Thrust Washer and slip it over the input shaft (cupped
side towards retaining ring) and up against the retaining ring assembly. Photo 6 & 7
5. Install the High Gear Pinion on to the
Input Shaft (dog teeth facing towards the
Thrust Washer). Rest it against the Thrust
Washer. Photo 8
5
7
6
