Figure 4-49 TCR_EL3 bit assignments
Table 4-88 shows the TCR_EL3 bit assignments.
RES
0
31 30 24 23 22 21 20 19 18 16 15 14 13 12 11 10 9 8 7 6 5
0
RES
0
SH0TG0PS
IRGN0
ORGN0
T0SZ
RES
0
TBI
RES
0
RES
1
RES
1
3263
RES
0
Table 4-88 TCR_EL3 bit assignments
Bits Name Function
[63:32] - Reserved,
RES0.
[31] - Reserved,
RES1.
[30:24] - Reserved,
RES0.
[23] - Reserved,
RES1.
