System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-105
ID021414 Non-Confidential
Table 4-97 on page 4-104 shows the FAR_EL2 bit assignments.
To access the FAR_EL2:
MRS <Xt>, FAR_EL2 ; Read EL2 Fault Address Register
MSR FAR_EL2, <Xt> ; Write EL2 Fault Address Register
4.3.63 Hypervisor IPA Fault Address Register, EL2
The HPFAR_EL2 characteristics are:
Purpose Holds the faulting IPA for some aborts on a stage 2 translation taken to
EL2.
Usage constraints This register is accessible as follows:
Configurations HPFAR_EL2[31:0] is mapped to AArch32 register HPFAR. See Hyp IPA
Fault Address Register on page 4-250.
Attributes HPFAR_EL2 is a 64-bit register.
Figure 4-57 shows the HPFAR_EL2 bit assignments.
Figure 4-57 HPFAR_EL2 bit assignments
Table 4-98 on page 4-104shows the HPFAR_EL2 bit assignments.
To access the HPFAR_EL:
MRS <Xt>, HPFAR_EL2 ; Read EL2 Fault Address Register
MSR HPFAR_EL2, <Xt> ; Write EL2 Fault Address Register
Table 4-97 FAR_EL2 bit assignments
Bits Name Function
[63:0] VA The faulting Virtual Address for all synchronous instruction or data aborts, or an exception from a misaligned PC,
taken in EL2.
If a memory fault that sets the FAR is generated from one of the data cache instructions, this field holds the address
specified in the register argument of the instruction.
EL0
EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
-- -RWRW RW
3940 063
FIPA[47:12]
RES
0
34
RES
0
Table 4-98 HPFAR_EL2 bit assignments
Bits Name Function
[63:40] - Reserved,
RES0.
[39:4] FIPA[47:12] Bits [47:12] of the faulting intermediate physical address. The equivalent upper bits in this field are
RES0.
[3:0] - Reserved,
RES0.
