System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-107
ID021414 Non-Confidential
Table 4-99 shows the L2CTLR_EL1 bit assignments.
To access the L2CTLR_EL1:
MRS <Xt>, S3_1_C11_C0_2 ; Read L2CTLR_EL1 into Xt
MSR S3_1_C11_C0_2, <Xt>; Write Xt to L2CTLR_EL1
4.3.65 L2 Extended Control Register
The L2ECTLR_EL1 characteristics are:
Purpose Provides additional
IMPLEMENTATION DEFINED control options for the L2
memory system. This register is used for dynamically changing, but
implementation specific, control bits.
Table 4-99 L2CTLR_EL1 bit assignments
Bits Name Function
[31:26] - Reserved,
RES0.
[25:24] Number of cores Number of cores present:
0b00
One core, core 0.
0b01
Two cores, core 0 and core 1.
0b10
Three cores, cores 0 to 2.
0b11
Four cores, cores 0 to 3.
These bits are read-only and the value of this field is set to the number of cores present in the
configuration.
[23] - Reserved, RES0.
[22] CPU Cache Protection CPU Cache Protection. Core RAMs are implemented:
0
Without ECC.
1
With ECC.
[21] SCU-L2 Cache
Protection
SCU-L2 Cache Protection. L2 cache is implemented:
0
Without ECC.
1
With ECC.
This field is RO.
[20:6] - Reserved,
RES0.
[5] L2 data RAM input
latency
L2 data RAM input latency:
0
1-cycle input delay from L2 data RAMs.
1
2-cycle input delay from L2 data RAMs.
This field is RO.
[4:1] - Reserved, RES0.
[0] L2 data RAM output
latency
L2 data RAM output latency:
0
2-cycle output delay from L2 data RAMs.
1
3-cycle output delay from L2 data RAMs.
This field is RO.
