System Control

ID021414 Non-Confidential

4.4.16 64-bit registers

Table 4-136 shows the 64-bit wide CP15 system registers, accessed by the

MCRR

and

MRRC

instructions. See the ARM

Architecture Reference Manual ARMv8, for ARMv8-A architecture

profile for more information.

Table 4-136 64-bit register summary

Op1 CRm Name Reset Description

0 c2 TTBR0 UNK Translation Table Base Register 0

1 c2 TTBR1 UNK Translation Table Base Register 1

4 c2 HTTBR UNK Hyp Translation Table Base Register

6 c2 VTTBR UNK Virtualization Translation Table Base Register

0 c7 PAR UNK Physical Address Register on page 4-251

0 c14 CNTPCT UNK Physical Timer Count Register

1 c14 CNTVCT UNK Virtual Timer Count Register

2 c14 CNTP_CVAL UNK Physical Timer CompareValue Register

3 c14 CNTV_CVAL UNK Virtual Timer CompareValue Register

4 c14 CNTVOFF UNK Virtual Timer Offset Register

6 c14 CNTHP_CVAL UNK Physical Timer CompareValue Register

0 c15 CPUACTLR

0x00000000004C8000

CPU Auxiliary Control Register on page 4-269

1 c15 CPUECTLR

0x0000000000000000

CPU Extended Control Register on page 4-271

2 c15 CPUMERRSR - CPU Memory Error Syndrome Register on page 4-273

3 c15 L2MERRSR - L2 Memory Error Syndrome Register on page 4-276
