System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-148
ID021414 Non-Confidential
4.4.17 AArch32 Identification registers
Table 4-137 shows the identification registers.
Table 4-137 Identification registers
Name CRn Op1 CRm Op2 Reset Description
MIDR c0 0 c0 0
0x410FD032 Main ID Register on page 4-157
CTR 1
0x84448004 Cache Type Register on page 4-188
TCMTR 2
0x00000000 TCM Type Register on page 4-160
TLBTR 3
0x00000000 TLB Type Register on page 4-160
MPIDR 5
-
a
Multiprocessor Affinity Register on page 4-158
REVIDR 6
0x00000000 Revision ID Register on page 4-159
ID_PFR0 c1 0
0x00000131 Processor Feature Register 0 on page 4-160
ID_PFR1 1
0x10011011
b
Processor Feature Register 0 on page 4-160
ID_DFR0 2
0x03010066 Debug Feature Register 0 on page 4-163
ID_AFR0 3
0x00000000 Auxiliary Feature Register 0 on page 4-164
ID_MMFR0 4
0x10101105 Memory Model Feature Register 0 on page 4-165
ID_MMFR1 5
0x40000000 Memory Model Feature Register 1 on page 4-166
ID_MMFR2 6
0x01260000 Memory Model Feature Register 2 on page 4-168
ID_MMFR3 7
0x02102211 Memory Model Feature Register 3 on page 4-170
ID_ISAR0 c2 0
0x02101110 Instruction Set Attribute Register 0 on page 4-172
ID_ISAR1 1
0x13112111 Instruction Set Attribute Register 1 on page 4-173
ID_ISAR2 2
0x21232042 Instruction Set Attribute Register 2 on page 4-175
ID_ISAR3 3
0x01112131 Instruction Set Attribute Register 3 on page 4-178
ID_ISAR4 4
0x00011142 Instruction Set Attribute Register 4 on page 4-179
ID_ISAR5 c0 0 c2 5
0x00011121
c
Instruction Set Attribute Register 5 on page 4-181
CCSIDR 1 c0 0 - Cache Size ID Register on page 4-183
CLIDR 1
0x0A200023
d
Cache Level ID Register on page 4-185
AIDR 7
0x00000000 Auxiliary ID Register on page 4-187
CSSELR 2 c0 0
0x00000000 Cache Size Selection Register on page 4-187
a. The reset value depends on the primary inputs, CLUSTERIDAFF1 and CLUSTERIDAFF2, and the number of cores that
the device implements.
b. Bits [31:28] are
0x1 if the GIC CPU interface is enabled, and 0x0 otherwise.
c. ID_ISAR5 has the value
0x00010001 if the Cryptography Extension is not implemented and enabled.
d. The value is
0x09200003 if the L2 cache is not implemented.
