Attributes ID_DFR0 is a 32-bit register.
Figure 4-81 shows the ID_DFR0 bit assignments.
Figure 4-81 ID_DFR0 bit assignments
Table 4-158 shows the ID_DFR0 bit assignments.
To access the ID_DFR0:
MRC p15,0,<Rt>,c0,c1,2 ; Read ID_DFR0 into Rt
Register access is encoded as follows:
4.5.9 Auxiliary Feature Register 0
This register is always
RES0.
Table 4-158 ID_DFR0 bit assignments
Bits Name Function
[31:28] - Reserved,
RES0.
[27:24] PerfMon Indicates support for performance monitor model:
0x3
Support for Performance Monitor Unit version 3 (PMUv3) system registers.
[23:20] MProfDbg Indicates support for memory-mapped debug model for M profile processors:
0x0
Processor does not support M profile Debug architecture.
[19:16] MMapTrc Indicates support for memory-mapped trace model:
0x1
Support for ARM trace architecture, with memory-mapped access.
In the Trace registers, the ETMIDR gives more information about the implementation.
[15:12] CopTrc Indicates support for coprocessor-based trace model:
0x0
Processor does not support ARM trace architecture, with CP14 access.
[11:8] - Reserved, RAZ.
[7:4] CopSDbg Indicates support for coprocessor-based Secure debug model:
0x6
Processor supports v8 Debug architecture, with CP14 access.
[3:0] CopDbg Indicates support for coprocessor-based debug model:
0x6
Processor supports v8 Debug architecture, with CP14 access.
Table 4-159 ID_DFR0 access encoding
coproc opc1 CRn CRm opc2
1111 000 0000 0001 010
