System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-166
ID021414 Non-Confidential
Table 4-160 shows the ID_MMFR0 bit assignments.
To access the ID_MMFR0:
MRC p15,0,<Rt>,c0,c1,4 ; Read ID_MMFR0 into Rt
Register access is encoded as follows:
4.5.11 Memory Model Feature Register 1
The ID_MMFR1 characteristics are:
Purpose Provides information about the memory model and memory management
support in AArch32.
Usage constraints This register is accessible as follows:
Table 4-160 ID_MMFR0 bit assignments
Bits Name Function
[31:28] InnerShr Indicates the innermost shareability domain implemented:
0x1
Implemented with hardware coherency support.
[27:24] FCSE Indicates support for Fast Context Switch Extension (FCSE):
0x0
Not supported.
[23:20] AuxReg Indicates support for Auxiliary registers:
0x1
Support for Auxiliary Control Register only.
[19:16] TCM Indicates support for TCMs and associated DMAs:
0x0
Not supported.
[15:12] ShareLvl Indicates the number of shareability levels implemented:
0x1
Two levels of shareability implemented.
[11:8] OuterShr Indicates the outermost shareability domain implemented:
0x1
Implemented with hardware coherency support.
[7:4] PMSA Indicates support for a Protected Memory System Architecture (PMSA):
0x0
Not supported.
[3:0] VMSA Indicates support for a Virtual Memory System Architecture (VMSA).
0x5
Support for:
• VMSAv7, with support for remapping and the Access flag.
• The PXN bit in the Short-descriptor translation table format descriptors.
• The Long-descriptor translation table format.
Table 4-161 ID_MMFR0 access encoding
coproc opc1 CRn CRm opc2
1111 000 0000 0001 100
EL0
(NS)
EL0
(S)
EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
- - RO RO RO RO RO
