System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-167
ID021414 Non-Confidential
Must be interpreted with ID_MMFR0, ID_MMFR2, and ID_MMFR3.
See:
• Memory Model Feature Register 0 on page 4-165.
• Memory Model Feature Register 2 on page 4-168.
• Memory Model Feature Register 3 on page 4-170.
Configurations ID_MMFR1 is architecturally mapped to AArch64 register
ID_MMFR1_EL1.
There is one copy of this register that is used in both Secure and
Non-secure states.
Attributes ID_MMFR1 is a 32-bit register.
Figure 4-83 shows the ID_MMFR1 bit assignments.
Figure 4-83 ID_MMFR1 bit assignments
Table 4-162 shows the ID_MMFR1 bit assignments.
To access the ID_MMFR1:
MRC p15, 0, <Rt>, c0, c1, 5; Read ID_MMFR1 into Rt
31 12 11 8 7 0
BPred
4328 27 2423 20 19 16 15
L1TstCln L1Uni L1Hvd L1UniSW L1HvdSW L1UniVA L1HvdVA
Table 4-162 ID_MMFR1 bit assignments
Bits Name Function
[31:28] BPred Indicates branch predictor management requirements:
0x4
For execution correctness, branch predictor requires no flushing at any time.
[27:24] L1TstCln Indicates the supported L1 Data cache test and clean operations, for Harvard or unified cache implementation:
0x0
None supported.
[23:20] L1Uni Indicates the supported entire L1 cache maintenance operations, for a unified cache implementation:
0x0
None supported.
[19:16] L1Hvd Indicates the supported entire L1 cache maintenance operations, for a Harvard cache implementation:
0x0
None supported.
[15:12] L1UniSW Indicates the supported L1 cache line maintenance operations by set/way, for a unified cache implementation:
0x0
None supported.
[11:8] L1HvdSW Indicates the supported L1 cache line maintenance operations by set/way, for a Harvard cache
implementation:
0x0
None supported.
[7:4] L1UniVA Indicates the supported L1 cache line maintenance operations by MVA, for a unified cache implementation:
0x0
None supported.
[3:0] L1HvdVA Indicates the supported L1 cache line maintenance operations by MVA, for a Harvard cache implementation:
0x0
None supported.
