ARM Cortex-A53 MPCore - Page 246

System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-185
ID021414 Non-Confidential
Table 4-181 shows the individual bit field and complete register encodings for the CCSIDR.
The CSSELR determines which CCSIDR to select.
To access the CCSIDR:
MRC p15, 1, <Rt>, c0, c0, 0 ; Read CCSIDR into Rt
Register access is encoded as follows:
4.5.21 Cache Level ID Register
The CLIDR characteristics are:
Purpose Identifies:
• The type of cache, or caches, implemented at each level.
• The Level of Coherency and Level of Unification for the cache
hierarchy.
Table 4-181 CCSIDR encodings
CSSELR Cache Size
Complete
register
encoding
Register bit field encoding
WT WB RA WA NumSets Associativity LineSize
0x0 L1 Data cache 8KB 0x7003E01A 0111 0x001F 0x003 0x2
16KB 0x7007E01A 0x003F 0x003 0x2
32KB 0x700FE01A 0x007F 0x003 0x2
64KB 0x701FE01A 0x00FF 0x003 0x2
0x1
L1 Instruction
cache
8KB 0x2007E00A 0010 0x003F 0x001 0x2
16KB 0x200FE00A 0x007F 0x001 0x2
32KB 0x201FE00A 0x00FF 0x001 0x2
64KB 0x203FE00A 0x001F 0x001 0x2
0x2
L2 cache 128KB 0x700FE07A 0111 0x007F 0x00F 0x2
256KB 0x701FE07A 0x00FF 0x00F 0x2
512KB 0x703FE07A 0x01FF 0x00F 0x2
1024KB 0x707FE07A 0x03FF 0x00F 0x2
2048KB 0x70FFE07A 0x07FF 0x00F 0x2
0x3-0xF
Reserved - - - - - - - - -
Table 4-182 CCSIDR access encoding
coproc opc1 CRn CRm opc2
1111 001 0000 0000 000
