System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-225
ID021414 Non-Confidential
Table 4-206 shows the TTBR0 bit assignments when TTBCR.EAE is 0.
To access the TTBR0 when TTBCR.EAE is 0:
MRC p15,0,<Rt>,c2,c0,0 ; Read TTBR0 into Rt
MCR p15,0,<Rt>,c2,c0,0 ; Write Rt to TTBR0
TTBR0 format when using the Long-descriptor translation table format
Figure 4-112 shows the TTBR0 bit assignments when TTBCR.EAE is 1.
Figure 4-112 TTBR0 bit assignments, TTBRC.EAE is 1
Table 4-206 TTBR0 bit assignments, TTBCR.EAE is 0
Bits Name Function
[31:7] TTB0 Translation table base 0 address, bits[31:x], where x is 14-(TTBCR.N). Bits [x-1:7] are RES0.
The value of x determines the required alignment of the translation table, that must be aligned to 2
x
bytes.
If bits [x-1:7] are not all zero, this is a misaligned Translation Table Base Address. Its effects are
CONSTRAINED
UNPREDICTABLE, where bits [x-1:7] are treated as if all the bits are zero. The value read back from those bits is
the value written.
[6] IRGN[1] See bit[0] for description of the IRGN field.
[5] NOS Not Outer Shareable bit. Indicates the Outer Shareable attribute for the memory associated with a translation
table walk that has the Shareable attribute, indicated by TTBR0.S is 1. The possible values are:
0
Outer Shareable.
1
Inner Shareable.
This bit is ignored when TTBR0.S is 0.
[4:3] RGN Region bits. Indicates the Outer cacheability attributes for the memory associated with the translation table
walks. The possible values are:
0b00
Normal memory, Outer Non-cacheable.
0b01
Normal memory, Outer Write-Back Write-Allocate Cacheable.
0b10
Normal memory, Outer Write-Through Cacheable.
0b11
Normal memory, Outer Write-Back no Write-Allocate Cacheable.
[2] - Reserved,
RES0.
[1] S Shareable bit. Indicates the Shareable attribute for the memory associated with the translation table walks. The
possible values are:
0
Non-shareable.
1
Shareable.
[0] IRGN[0] Inner region bits. Indicates the Inner Cacheability attributes for the memory associated with the translation table
walks. The possible values of IRGN[1:0] are:
0b00
Normal memory, Inner Non-cacheable.
0b01
Normal memory, Inner Write-Back Write-Allocate Cacheable.
0b10
Normal memory, Inner Write-Through Cacheable.
0b11
Normal memory, Inner Write-Back no Write-Allocate Cacheable.
