System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-229
ID021414 Non-Confidential
Write access to the Secure copy of TTBCR is disabled if the
CP15SDISABLE signal is asserted HIGH.
Attributes TTBCR is a 32-bit register.
There are two formats for this register. TTBCR.EAE determines which format of the register is
used. This section describes:
• TTBCR format when using the Short-descriptor translation table format.
• TTBCR format when using the Long-descriptor translation table format.
TTBCR format when using the Short-descriptor translation table format
Figure 4-115 shows the TTBCR bit assignments when TTBCR.EAE is 0.
Figure 4-115 TTBCR bit assignments, TTBCR.EAE is 0
Table 4-210 shows the TTBCR bit assignments when TTBCR.EAE is 0.
TTBCR format when using the Long-descriptor translation table format
Figure 4-116 on page 4-230 shows the TTBCR bit assignments when TTBCR.EAE is 1.
31 30 65432
0
N
RES
0
PD1EAE
PD0
RES
0
Table 4-210 TTBCR bit assignments, TTBCR.EAE is 0
Bits Name Function
[31] EAE Extended Address Enable.
0 Use the 32-bit translation system, with the Short-descriptor translation table format.
[30:6] - Reserved,
RES0.
[5] PD1 Translation table walk disable for translations using TTBR1. This bit controls whether a translation table walk is
performed on a TLB miss, for an address that is translated using TTBR1. The possible values are:
0 Perform translation table walks using TTBR1.
1 A TLB miss on an address that is translated using TTBR1 generates a Translation fault. No
translation table walk is performed.
[4] PD0 Translation table walk disable for translations using TTBR0. This bit controls whether a translation table walk is
performed on a TLB miss for an address that is translated using TTBR0. The possible values are:
0 Perform translation table walks using TTBR0.
1 A TLB miss on an address that is translated using TTBR0 generates a Translation fault. No
translation table walk is performed.
[3] - Reserved,
RES0.
[2:0] N Indicate the width of the base address held in TTBR0. In TTBR0, the base address field is bits[31:14-N]. The value
of N also determines:
• Whether TTBR0 or TTBR1 is used as the base address for translation table walks.
• The size of the translation table pointed to by TTBR0.
N can take any value from 0 to 7, that is, from 0b000 to 0b111.
When N has its reset value of 0, the translation table base is compatible with ARMv5 and ARMv6.
Resets to 0.
