The TRCEXTINSELR can be accessed through the internal memory-mapped interface and the
external debug interface, offset
0x120 .
13.8.20 Counter Reload Value Registers 0-1
The TRCCNTRLDVRn characteristics are:
Purpose Defines the reload value for the counter.
Usage constraints Accepts writes only when the trace unit is disabled.
Configurations Available in all configurations.
Attributes See the register summary in Table 13-3 on page 13-10
Figure 13-22 shows the TRCCNTRLDVRn bit assignments.
Figure 13-22 TRCCNTRLDVRn bit assignments
Table 13-23 shows the TRCCNTRLDVRn bit assignments.
The TRCCNTRLDVRn registers can be accessed through the internal memory-mapped
interface and the external debug interface, offsets:
TRCCNTRLDVR0
0x140 .
TRCCNTRLDVR1
0x144 .
13.8.21 Counter Control Register 0
The TRCCNTCTLR0 characteristics are:
Purpose Controls the counter.
Usage constraints Accepts writes only when the trace unit is disabled.
Configurations Available in all configurations.
Attributes See the register summary in Table 13-3 on page 13-10.
Figure 13-23 shows the TRCCNTCTLR0 bit assignments.
Figure 13-23 TRCCNTCTLR0 bit assignments
31 16 15 0
RES0 VALUE
Table 13-23 TRCCNTRLDVRn bit assignments
Bits Value Function
[31:16] - Reserved,
RES0.
[15:0] VALUE Defines the reload value for the counter. This value is loaded into the counter each time the reload event occurs.
RES
0
RES
0
RES
0
31 16 15 14 12 11 8 7 6 4 3 0
RLDSEL CNTSEL
RLDSELF CNTTYPE
17
RLDTYPE
