Page #144 background imageLoading...
Page #144 background image
Debug
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. 10-5
ID073015 Non-Confidential
10.4 Debug register summary
You can access the debug registers:
through the CP14 interface. The debug registers are mapped to coprocessor instructions.
through the APB using the relevant offset when PADDRDBG[12]=0, with the following
exceptions:
DBGRAR
—DBGSAR
DBGSCR-int
DBGTR-int.
External views of DBSCR and DBGTR are accessible through memory-mapped APB access.
Table 10-1 shows the CP14 interface registers. All other registers are described in the ARM
Architecture Reference Manual.
Table 10-1 CP14 Debug register summary
Register
number
Offset CRn Op1 CRm Op2 Name Type Description
0
0x000
c0 0 c0 0
DBGDIDR
ab
RO See the ARM Architecture Reference
Manual
-- c10c00
DBGDRAR
a
RO
-- c20c00
DBGDSAR
a
RO
-- c00c10
DBGDSCRint
ab
RO
5- c00c50
DBGDTRRXint
a
RO
DBGDTRTXint
a
WO Reserved
6
0x018
c0 0 c6 0 DBGWFAR RW Use of DBGWFAR is deprecated in
the ARMv7 architecture, because
watchpoints are synchronous
7
0x01C
c0 0 c7 0 DBGVCR RW See the ARM Architecture Reference
Manual
8 - - - - - - - Reserved
9
0x024
c0 0 c9 0 DBGECR RAZ/WI Not implemented
10
0x028
c0 0 c10 0 DBGDSCCR RAZ/WI
11
0x02C
c0 0 c11 0 DBGDSMCR RAZ/WI
12-31 - - - - - - - Reserved
32
0x080
c0 0 c0 2 DBGDTRRXext RW See the ARM Architecture Reference
Manual
33
0x084
c0 0 c1 2 DBGITR WO
33
0x084
c0 0 c1 2 DBGPCSR RO
34
0x088
c0 0 c2 2 DBGDSCRext RW
35
0x08C
c0 0 c3 2 DBGDTRTXext RW
36
0x090
c0 0 c4 2 DBGDRCR WO See the ARM Architecture Reference
Manual
