ARM Cortex A9 User Manual

Signal Descriptions
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. A-8
ID073015 Non-Confidential
A.7 AXI interfaces
In Cortex-A9 designs there can be two AXI master ports. The following sections describe the
AXI interfaces:
• AXI Master0 signals data accesses
• AXI Master1 signals instruction accesses on page A-11.
A.7.1 AXI Master0 signals data accesses
The following sections describe the AXI Master0 interface signals used for data read and write
accesses:
• Write address channel signals for AXI Master0
• Write data channel signals on page A-9
• Write response channel signals on page A-10
• Read address channel signals for AXI Master0 on page A-10
• Read data channel signals on page A-11
• AXI Master0 Clock enable signals on page A-11.
Write address channel signals for AXI Master0
Table A-8 shows the AXI write address channel signals for AXI Master0.
Table A-8 Write address channel signals for AXI Master0
Name I/O
Source or
destination
Description
AWADDRM0[31:0] O AXI system devices Address.
AWBURSTM0[1:0] O Burst type = b01, INCR incrementing burst.
AWCACHEM0[3:0] O Cache type giving additional information about cacheable characteristics,
determined by the memory type and Outer cache policy for the memory region.
AWIDM0[1:0] O Request ID.

ARM Cortex A9 Specifications

General

Architecture	ARMv7-A
Cores	1-4
SIMD Extensions	NEON
ISA	ARM
Microarchitecture	Cortex-A9
Instruction Width	32-bit
Data Width	32-bit
MMU	Yes
Instruction Set	ARMv7-A
Clock Speed	Up to 2 GHz
L1 Cache	32 KB Instruction, 32 KB Data (per core)
Process Technology	40 nm, 28 nm
Floating Point Unit	VFPv3
Pipeline Depth	8 stages
Power Consumption	Low power design
