ARM Cortex A9 User Manual

Cycle Timings and Interlock Behavior
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. B-3
ID073015 Non-Confidential
B.2 Data-processing instructions
Table B-1shows the execution unit cycle time for data-processing instructions.
Table B-1 shows the following cases:
no shift on source registers
For example,
ADD r0, r1, r2
shift by immediate source register
For example,
ADD r0, r1, r2 LSL #2
shift by register
For example,
ADD r0, r1, r2 LSL r3 .
Table B-1 Data-processing instructions cycle timings
Instruction No shift
Shift by
Constant Register
MOV 11 2
AND , EOR , SUB , RSB , ADD , ADC , SBC , RSC , CMN , ORR , BIC , MVN , TST , TEQ , CMP 12 3
QADD , QSUB , QADD8 , QADD16 , QSUB8 , QSUB16 , SHADD8 , SHADD16 , SHSUB8 , SHSUB16 , UQADD8 , UQADD16 ,
UQSUB8 , UQSUB16 , UHADD8 , UHADD16 , UHSUB8 , UHSUB16 , QASX , QSAX , SHASX , SHSAX , UQASX , UQSAX , UHASX ,
UHSAX
2- -
QDADD , QDSUB , SSAT , USAT 3- -
PKHBT , PKHTB 12 -
SSAT16 , USAT16 , SADD8 , SADD16 , SSUB8 , SSUB16 , UADD8 , UADD16 , USUB8 , USUB16 , SASX , SSAX , UASX , USAX 1- -
SXTAB , SXTAB16 , SXTAH , UXTAB , UXTAB16 , UXTAH 3- -
SXTB , STXB16 , SXTH , UXTB , UTXB16 , UXTH 2- -
BFC , BFI , UBFX , SBFX 2- -
CLZ , MOVT , MOVW , RBIT , REV , REV16 , REVSH , MRS 1- -
MSR not modifying mode or control bits. See Serializing instructions on page B-9.1--

ARM Cortex A9 Specifications

General

Architecture	ARMv7-A
Cores	1-4
SIMD Extensions	NEON
ISA	ARM
Microarchitecture	Cortex-A9
Instruction Width	32-bit
Data Width	32-bit
MMU	Yes
Instruction Set	ARMv7-A
Clock Speed	Up to 2 GHz
L1 Cache	32 KB Instruction, 32 KB Data (per core)
Process Technology	40 nm, 28 nm
Floating Point Unit	VFPv3
Pipeline Depth	8 stages
Power Consumption	Low power design
