Signal Descriptions
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. A-2
ID073015 Non-Confidential
A.1 Clock signals
The Cortex-A9 processor has a single externally generated global clock. Table A-1 shows the
clock and clock control signals.
Table A-1 Clock and clock control signals
Name I/O Source Description
CLK I Clock controller Global clock.
See Clocking and resets on page 2-6.
MAXCLKLATENCY[2:0] I Implementation-specific static value Controls dynamic clock gating delays.
This pin is sampled during reset of the processor.
See Power Control Register on page 4-41.
