Debug
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. 10-13
ID073015 Non-Confidential
10.6 Debug management registers
The Debug management registers define the standardized set of registers that is implemented by
all CoreSight components. This section describes these registers.
You can access these registers:
through the internal CP14 interface
through the APB using the relevant offset when PADDRDBG[12]=0
See the ARM Architecture Reference Manual, ARMv7-A and ARMv7-R edition for additional
information about these registers.
Table 10-9 shows the contents of the management registers for the Cortex-A9 debug unit.
10.6.1 Peripheral Identification Registers
The Peripheral Identification Registers are read-only registers that provide standard information
required by all components that conform to the ARM Debug interface v5 specification. The
Peripheral Identification Registers are accessible from the Debug APB bus. Only bits [7:0] of
each register are used. The remaining bits are Read-As-Zero. The values in these registers are
fixed.
Table 10-9 Debug management registers
Register
number
Offset Name CRn Op1 CRm OP2 Type Description
960
0xF00
DBGITCTRL c7 0 c0 4 RAZ/
WI
Integration Mode Control Register
961-999
0xF04-
0xF9C
-RAZReserved
1000
0xFA0
DBGCLAIMSET c7 0 c8 6 RW Claim Tag Set Register
1001
0xFA4
DBGCLAIMCLR c7 0 c9 6 RW Claim Tag Clear Register
1002-
1003
0xFA8-
0xFBC
-RAZReserved
1004
0xFB0
DBGLAR c7 0 c12 6 WO Lock Access Register
1005
0xFB4
DBGLSR c7 0 c13 6 RO Lock Status Register
1006
0xFB8
DBGAUTHSTATUS c7 0 c14 6 RO Authentication Status Register
1007-
1009
0xFBC-
0xFC4
-RAZReserved
1010
0xFC8
DBGDEVID c7 0 c2 7 RAZ/
WI
Debug Device ID Register
1011
0xFCC
DBGDEVTYPE c7 0 c3 7 RO Device Type Register
1012-
1023
0xFD0-
0xFEC
DBGPID c7 0 c4-c8 7 RO See Peripheral Identification
Registers.
1020-
1023
0xFF0-
0xFFC
DBGCID c7 0 c12-c15 7 RO See Component Identification
Registers on page 10-14
