ARM Cortex A9 - B.4 Multiplication instructions

Cycle Timings and Interlock Behavior
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. B-7
ID073015 Non-Confidential
B.4 Multiplication instructions
Table B-4 on page B-6 shows the cycle timings for multiplication instructions.
Table B-5 Multiplication instruction cycle timings
Instruction Cycles Result latency
MUL(S) , MLA(S) 24
SMULL(S) , UMULL(S) , SMLAL(S) , UMLAL(S) 3 4 for the first written register
5 for the second written register
SMULxy , SMLAxy , SMULWy , SMLAWy 13
SMLALxy 2 3 for the first written register
4 for the second written register
SMUAD , SMUADX , SMLAD , SMLADX , SMUSD , SMUSDX , SMLSD , SMLSDX 13
SMMUL , SMMULR , SMMLA , SMMLAR , SMMLS , SMMLSR 24
SMLALD , SMLALDX , SMLSLD , SMLDLDX 2 3 for the first written register
4 for the second written register
UMAAL 3 4 for the first written register
5 for the second written register
