Recommended port mode setting for LACP
switch(config)# show interfaces config
Port Settings
Port Type | Enabled Mode Flow Ctrl MDI
----- --------- + ------- ------------ --------- ----
1 10/100TX | Yes Auto Enable Auto
2 10/100TX | Yes Auto Enable MDI
A port trunk in a Spanning Tree listing
Port Type Cost Priority State | Designated Bridge
----- --------- ---- -------- ---------- + -----------------
C3 100/1000T 5 12B Forwarding | 0020c1-b27ac0
C4 100/1000T 5 12B Forwarding | 0060b0-889e00
C5 100/1000T 5 12B Disabled |
C6 100/1000T 5 12B Disabled |
Trk1 1 64 Forwarding | 0001e7-a0ec00
Viewing and configuring a static trunk group (Menu)
IMPORTANT: Configure port trunking before you connect the trunked links to another switch, routing
switch, or server. Otherwise, a broadcast storm could occur. (If you need to connect the ports before
configuring them for trunking, you can temporarily disable the ports until the trunk is configured. See
"Enabling or Disabling Ports and Configuring Port Mode".)
This procedure uses the Port/Trunk Settings screen to configure a static port trunk group on the switch.
Procedure
1. Follow the procedures in the preceding IMPORTANT note.
2. From the Main Menu, select:
2. Switch Configuration…
2. Port/Trunk Settings
