4 | Print-Server-Trunk 10/100TX | Trk1 Trunk
5 | Print-Server-Trunk 10/100TX | Trk1 Trunk
7 | 10/100TX | Trk2 Trunk
8 | 10/100TX | Trk2 Trunk
Viewing static LACP and dynamic LACP trunk data
Syntax:
show lacp
Lists data for only the LACP-configured ports.
Example:
Ports A1 and A2 have been previously configured for a static LACP trunk. (For more on the Active parameter,
see table "
LACP port status data".)
A show LACP listing
switch# show lacp
LACP
LACP Trunk Port LACP Admin Oper
Port Enabled Group Status Partner Status Key Key
---- ------- ------- ------- ------- ------- ------ ------
Al Active Trkl Up Yes Success 0 250
A2 Active Trkl Up Yes Success 0 250
A3 Active A3 Down No Success 0 300
A4 Passive A4 Down No Success 0 0
A5 Passive A5 Down No Success 0 0
A6 Passive A6 Down No Success 0 0
For a description of each of the above-listed data types, see table "
LACP port status data".
Dynamic LACP Standby Links
Dynamic LACP trunking enables you to configure standby links for a trunk by including more than eight ports in a
dynamic LACP trunk configuration. When eight ports (trunk links) are up, the remaining link(s) will be held in
standby status. If a trunked link that is “Up” fails, it will be replaced by a standby link, which maintains your
intended bandwidth for the trunk. (Refer to also the “Standby” entry under “Port Status” in "Table 4-5. LACP Port
Status Data".) In the next Example:, ports A1 through A9 have been configured for the same LACP trunk. Notice
that one of the links shows Standby status, while the remaining eight links are “Up”.
A Dynamic LACP trunk with one standby link
switch# show lacp
LACP
LACP Trunk Port LACP Admin Oper
Port Enabled Group Status Partner Status Key Key
---- ------- ----- ------ ------- ------ ---- -----
Al Active Dyn1 Up Yes Success 100 100
A2 Active Dyn1 Up Yes Success 100 100
A3 Active Dyn1 Up Yes Success 100 100
A4 Active Dyn1 Up Yes Success 100 100
A5 Active Dyn1 Up Yes Success 100 100
A6 Active Dyn1 Up Yes Success 100 100
A7 Active Dyn1 Up Yes Success 100 100
Chapter 5 Port Trunking 113
