Aruba 2530 - Viewing the Mirroring Configuration for a Specific Session

Type Indicates whether the mirroring session is local (port), remote (IPv4), or MAC-based
(mac) for local or remote sessions.
UDP Source Addr The IP address configured for the source VLAN or subnet on which the monitored
source interface exists. In the configuration of a remote session, the same UDP source
address must be configured on the source and destination switches.
UDP port The unique UDP port number that identifies a remote session. In the configuration of a
remote session, the same UDP port number must be configured on the source and
destination switches.
UDP Dest Addr The IP address configured for the destination VLAN or subnet on which the remote exit
port exists. In the configuration of a remote session, the same UDP destination address
must be configured on the source and destination switches.
Dest Port
Identifies the exit port for a remote session on a remote destination switch.
Figure 51: Displaying the currently configured mirroring sessions on the switch
Viewing the mirroring configuration for a specific session
Syntax
show monitor [1 - 4 | name name-str]
Displays detailed configuration information for a specified local mirroring session on a source switch.
Session Displays the number of the specified session.
Session Name Displays the name of the session, if configured.
Policy Indicates whether the source is using a classifier-based mirroring policy to select
inbound IPv4 or IPv6 traffic for mirroring.
Mirroring Destination For a local mirroring session, displays the port configured as the exit port on the source
switch.
Table Continued
