Viewing port status and configuring port parameters
Connecting transceivers to fixed-configuration devices
If the switch either fails to show a link between an installed transceiver and another device or demonstrates errors
or other unexpected behavior on the link, check the port configuration on both devices for a speed and/or duplex
(mode) mismatch.
• To check the mode setting for a port on the switch, use either the Port Status screen in the menu interface or
show interfaces brief in the CLI (see Viewing port status and configuration (CLI)).
• To display information about the transceivers installed on a switch, enter the show tech receivers
command in the CLI (The show tech transceivers command on page 63).
Viewing port configuration (Menu)
The menu interface displays the configuration for ports and (if configured) any trunk groups.
From the Main Menu, select:
1. Status and Counters 4. Port Status
A switch port status screen
==========================- CONSOLE - MANAGER MODE -==========================
Status and Counters - Port Status
Intrusion MDI Flow Bcast
Port Type Alert Enabled Status Mode Mode Ctrl Limit
----- --------- --------- ------- ------ ---------- ----- ----- ------
1 100/1000T No Yes Down 100FDx Auto off 0
2 100/1000T No Yes Down 1000FDx Auto off 0
3 100/1000T No Yes Down 1000FDx Auto off 0
4 100/1000T No Yes Down 1000FDx Auto off 0
5 100/1000T No Yes Down 1000FDx Auto off 0
6 100/1000T No Yes Down 1000FDx Auto off 0
7 100/1000T No Yes Down 1000FDx Auto off 0
8 100/1000T No Yes Down 1000FDx Auto off 0
9 100/1000T No Yes Down 1000FDx Auto off 0
10 100/1000T No Yes Down 1000FDx Auto off 0
11 100/1000T No Yes Down 1000FDx Auto off 0
Actions-> Back Intrusion log Help
Return to previous screen.
Use up/down arrow keys to scroll to other entries, left/right arrow keys to
change action selection, and <Enter> to execute action.
Chapter 3
Port Status and Configuration
Chapter 3 Port Status and Configuration 55
