Received disconnect from 10.0.12.31: 2: Wait for previous
session to complete
lost connection
Attempt to start a second session
The switch supports only one SFTP session or one SCP session at a time. If a second session is initiated (For
example, an SFTP session is running and then an SCP session is attempted), the following error message may
appear on the client console:
Received disconnect from 10.0.12.31: 2: Other SCP/SFTP
session running
lost connection
Using Xmodem to download switch software from a PC or UNIX
workstation
This procedure assumes that:
• The switch is connected via the Console RS-232 port to a PC operating as a terminal. (For information on
connecting a PC as a terminal and running the switch console interface, see the installation and getting started
guide you received with the switch.)
• The switch software is stored on a disk drive in the PC.
• The terminal emulator you are using includes the Xmodem binary transfer feature. (For example, in the
HyperTerminal application included with Windows NT, you would use the Send File option in the Transfer
drop-down menu.)
Downloading to primary flash using Xmodem (Menu)
NOTE: The menu interface accesses only the primary flash.
Procedure
1. From the console Main Menu, select
7. Download OS
2. Press [E] (for Edit).
3. Use the Space bar to select XMODEM in the Method field.
4. Press [Enter], then [X] (for eXecute) to begin the software download.
The following message appears:
Press enter and then initiate Xmodem transfer from the attached computer.....
5. Press [Enter] and then execute the terminal emulator commands to begin Xmodem binary transfer.
For example, using HyperTerminal:
a. Click on Transfer, then Send File.
b. Enter the file path and name in the Filename field.
Chapter 14 File Transfers 271
