110-TYPE HARDWARE
Table 3-J shows an algorithm that provides approximate patch cord requirements based on
system line size.
TABLE 3-J. 110 Patch Cord Requirements
Line Size Patch Cord
Length
Percent of Line
Size Required
0-216
2 Feet
3 Feet
4 Feet
5 Feet
6 Feet
7 Feet
8 Feet
9 Feet
10.0%
16.5%
29.3%
26.0%
18.2%
0%
0%
0%
216-648
2 Feet
3 Feet
4 Feet
5 Feet
6 Feet
7 Feet
8 Feet
9 Feet
5.5%
15.5%
29.3%
27.0%
15.9%
6.8%
0%
0%
648-800
2 Feet
3 Feet
4 Feet
5 Feet
6 Feet
7 Feet
8 Feet
9 Feet
3.0%
10.3%
22.1%
25.7%
22.5%
8.5%
5.7%
2.2%
EQUIPMENT ROOM HARDWARE AND CABLING INSTALLATION
Hardware Installation
The procedures provided in this guide for installing hardware are written so that one system
technician can do the installation. Procedures are provided for installing the following:
Cross-Connect Field
Wall Mounting 110A-Type Terminal Blocks
Wall Mounting 110P-Type Terminal Blocks
Frame Mounting 110P-Type Terminal Blocks
Cable Slack Managers
3-46
