66-TYPE HARDWARE
PagePac PAGING SYSTEM
The PagePac* paging systems use a single port of a system circuit pack to provide single or
multi-zone loudspeaker paging. A PagePac system may be used in addition to the standard
loudspeaker paging and code-calling capabilities of the system.
Three models are available:
●
●
●
PagePac 20
PagePac VS
PagePac 50/100/200
PagePac 20
The PagePac 20 is a 20 watt amplifier that can be used alone to provide a single zone of
paging (Figure 4-79) or it can be equipped with a Zone-Mate 9 or 39 to provide multiple
paging zones (Figure 4-80). If the PagePac 20 is used alone a 278A adapter must be used.
PagePac VS
The PagePac VS is a 35 watt amplifier that provides up to 3 paging zones. The PagePac VS
does not require a 278A adapter. The connections for the PagePac VS are shown in Figure
4-81.
PagePac 50/100/200
The 50/100/200 PagePac Paging system will mount directly on the wall or on a 23-inch
(58.4-cm) relay rack using the appropriate adapters. The unit provides 3 wattages 50, 100
and 200. The PagePac amplicenter can be used alone to provide a single zone of paging
(Figure 4-82) or add-on units can be provided to create a paging system with up to 24 paging
zones (Figure 4-83). If the PagePac 50/100/200 amplicenter is used alone, a 278A adapter
must be used.
* Registered trademark of Harris Corporation, Dracon Division
4-125
