AUTOFLAME Mk8 MM User Manual

18 Operation
Mk8 MM Manual Page | 335
18.10.2 EGA – Temperature
Figure 18.10.2.i EGA – Temperature
Press in the EGA Gas screen in Figure 18.10.1.i to vie the EGA Temperature screen, which shows
the exhaust and ambient temperature histories.
This data is logged for 24 hours on the MM. Use the buttons to change the timescale of the data
displayed and press and drag on the axis to zoom in/out of the graph.
This information is logged for 2 years on the DTI when connected with the MM.
Note: Power cycling the MM or changing fuel will reset the 24-hour history data log on the MM.
Press to force the EGA into an air calibration when it is next in a safe condition (not trimming and
span gas calibration).
