AUTOFLAME Mk8 MM User Manual

16 Heat Flow
Mk8 MM Manual Page | 271
16.2 Expansion Options
The table below shows the Expansion Options used for configuring Heat Flow Metering.
# Default Range Description
120
0
Flow: Heat Flow Function
Used to enable and define the Heat Flow function as well as enabling a
spare temperature sensor
0
Disabled
1
Steam Flow with Default Values
2
Steam Flow
3
Steam Flow with Economiser
4
Steam Flow with Deaerator
6
Steam Flow with Deaerator and Feed Sensor
7
Hot Water Flow with Default Values
8
Hot Water Flow
9
Hot Water flow with Economiser
10
Steam Flow from Feed Water Meter
11
Steam Flow from Feed Water Meter and Feed Sensor
12
Spare Temperature Sensor Only
121
100
Flow: Boiler Standing Losses
The boiler standing losses are known as the heat lost from the boiler
surfaces and pipework through radiation, and is set as a percentage of the
maximum continuous rating of the boiler.
0 – 200
0.00 – 2.00%
122
100
Flow: Blow Down Losses
This is the typical losses resulting from top blowdown and bottom
blowdown operations.
0 – 100
0.00 – 10.0%
123
0
Flow: Blow Down Loss Calculation Method
For setting 0, a fixed blow down loss is used in the steam or hot water flow
metering, set in expansion option 122.
For setting 1, the blow down loss will change according to the current
firing rate in the metering calculation.
0
Fixed loss
1
Loss proportional to firing rate
124
100
Flow: Make Up Flowmeter Range
The make-up water flowmeter range is only relevant if the steam flow
metering function has been set with deaerator in expansion option 120.
0 – 9999
0.0 – 999.9 litres/s or gallon/s (see parameter 40)
125
100
Flow: Condensate Flowmeter Range
The condensate flowmeter range is only relevant if the steam flow
metering function has been set with deaerator in expansion option 120.
0 – 9999
0.0 – 999.9 litres/s or gallon/s (see parameter 40)
126
80
Flow: Default Feedwater Temperature
If the heat flow function is set for steam or hot water flow metering using
default values, then this default feedwater temperature is used for the
steam or hot water flow metering calculations.
0 – 300
O
C or
O
F (see parameter 40)
