AUTOFLAME Mk8 MM User Manual

15 First Outs
Mk8 MM Manual Page | 267
15.3.4 First Out Function
In the First Outs screen, press on the First Out number to be configured and select the function of first out
when upon the active state set for high or low. Please see section 8.1 for more information on the first out
functions and active input state.
Function When Active
Description
Disabled
Does not function.
Monitor
Burner continues firing, but the events will be logged.
Non-recycle
Burner stops firing and the first out must be reset for the burner to restart.
Recycle
Burner stops firing and restarts automatically when the input state changes.
Stop EGA Sampling
Burner continues firing, but the EGA stops sampling.
Stops EGA Trimming
Burner continues firing, but the EGA trim stops operating.
External Stat
Used if external stat is optioned.
Figure 15.3.4 Configuring a First Out
