AUTOFLAME Mk8 MM User Manual

1 Mk8 MM Overview, Specifications and Wiring
Mk8 MM Manual Page | 23
1.3.4 MM Terminals Description
S
All terminals marked S are internally connected. They are provided for connections to the
various screened cables.
1
Current Input, 0-20mA/ 4-20mA. For channel 5 only. Can be connected to the current output of
a VSD or tachometer system or 4-20mA servomotor feedback
2
Voltage Input, 0-10V. For channel 5 only. Can be connected to the voltage output of a VSD or
tachometer system
3
0V common for Terminals 1 or 2
4
Current Input, 0-20mA/ 4-20mA. For channel 6 only. Can be connected to the current output of
a VSD or tachometer system or 4-20mA servomotor feedback
5
Voltage Input, 0-10V. For channel 6 only. Can be connected to the voltage output of a VSD or
tachometer system
6
0V common for Terminals 4 or 5
7
Current Input, 4-20mA. Used for external modulation or external required setpoint
8
Voltage Input, 2-10V. Used for external modulation or external required setpoint
9
0V common for Terminals 7 or 8
10
Current Output, 0-20mA/ 4-20mA. For channel 5 only. Can be connected to the current input of
a VSD or tachometer system or 4-20mA servomotor feedback
11
Voltage Output, 0-10V. For channel 5 only. Can be connected to the voltage input of a VSD or
tachometer system
12
0V common for Terminals 10 or 11
13
Current Output, 0-20mA/ 4-20mA. For channel 6 only. Can be connected to the current input of
a VSD or tachometer system or 4-20mA servomotor feedback
14
Voltage Output, 0-10V. For channel 6 only. Can be connected to the voltage input of a VSD or
tachometer system
15
0V common for Terminals 13 or 14
16
Current Output, 4-20mA/ 0-20mA. Varies in accordance with firing rate
17
Voltage Output, 0-10V/ 2-10V. Varies in accordance with firing rate
18
0V common for Terminals 16 or 17
19, 20
Connections to an Autoflame outside temperature sensor
21, 22
Connections to an Autoflame self-check UV sensor
23, 24
Communications port connections for multi-burner operation
25, 26
Communications port connections to an Exhaust Gas Analyser (EGA)
27, 28
Communications port connections for DTI and/or IBS
29, 30
Digital communications connections to an Autoflame IR scanner
31, 32
Digital communications connections to an Autoflame air pressure sensor and/or Autoflame gas
pressure sensor
33
0V supply to an Autoflame air pressure sensor and/or Autoflame gas pressure sensor
