1 Mk8 MM Overview, Specifications and Wiring
Mk8 MM Manual Page | 24
+12V supply to an Autoflame air pressure sensor and/or Autoflame gas pressure sensor
Signal inputs from Autoflame oil pressure sensor
0V supply to an Autoflame oil pressure sensor and/or Autoflame IR scanner
+13.5V supply to an Autoflame oil pressure sensor and/or Autoflame IR scanner
0V supply to an Autoflame temperature or pressure detector, 0-10V external load detector
Signal input from an Autoflame temperature or pressure detector, 0-10V external load detector
12V supply to an Autoflame pressure detector
0V supply to channel 1 and channel 2 servomotors
+12V supply to channel 1 and channel 2 servomotors
Signal from channel 1 servomotor, indicating position
Signal from channel 2 servomotor, indicating position
Signal from channel 3 servomotor, indicating position
Signal from channel 4 servomotor, indicating position
0V Supply to channel 3 and channel 4 servomotors
+12V supply to channel 3 and channel 4 servomotors
Connections to an Autoflame UV scanner
Mains voltage input – external auxiliary delay to purge/ secondary proving set in
option/parameter 157
Mains voltage input – burner on/off signal, running interlock circuit
Mains voltage input – air proving switch
Mains voltage input - proving circuits, e.g. gas valve proof of closure
Mains voltage input- lockout reset
Mains voltage output – call for heat
Mains voltage output – burner motor
Mains voltage output – start/pilot valve
Mains voltage output – main fuel valve 1
Mains voltage output – main fuel valve 2
Mains voltage output – vent valve
Mains voltage output – ignition transformer
Fuel 2 Main Valve 1(Dual Fuel Output Mode & Change on the Fly)
Mains supply – live/hot
Mains voltage output, power to servomotors and/or servomotor stepdown transformer
