11 Top Blowdown
Mk8 MM Manual Page | 210
11.4 TDS Probe
11.4.1 Specification
Figure 11.4.1.i TDS Probe
The TDS probe part number: TDS70003
Timed pulsed top blowdown or continuous top blowdown operation selectable on the Mk8 MM.
Self-cleaning design. Turbulence created during the blowdown sequence ensures that the probe
remains effectively free of scale or deposited solids that could be held in suspension.
Stainless steel housing.
PTFE coated.
Specifications
Metric
Imperial
Supplied flying lead length
2
6ft
Probe connection (quick connect)
½” BSP Parallel Tread
External temperature rating
0 - 70°C
32 - 158°F
Ingress Protection
IP68
NEMA 6P
Nominal Size of Line
15mm
½”
Maximum Allowable Pressure (with modulating valve)
16 Bar
392 PSI
Maximum Allowable Pressure (with solenoid valve)
10 Bar
145 PSI
Maximum Allowable Temperature
200°C
392°F
Test Pressure
40 Bar
580 PSI
