AUTOFLAME Mk8 MM User Manual

10 Water Level Control
Mk8 MM Manual Page | 175
10.5.4 Installation Safety Guidelines
The notes and mechanical executions implicit in the following diagrams for capacitance probe installation are
to be used for guidance purposes only. Local, state and national codes must be adhered to in all cases. It is
important to use only qualified and experience installation personnel who have been factory trained.
Under all boiler operation codes that Autoflame is aware of, it is not permitted to install only two capacitance
probes without an additional water level detection device. When the capacitance probes are installed on a
boiler application in this way, the boiler must be protected using a separate auxiliary low water cut-off device.
For fire tube steam boilers, a sight gauge glass must be installed to visually indicate the level of the water in
the boiler. The water in the sight gauge glass is considerably colder than the water in the boiler and does not
contain bubbles or current effects.
Installation diagrams:
10.5.4.A
Capacitance Probe – Externally Mounted Pots
10.5..4.B
Capacitance Probe – Internally Mounted Pots
10.5.4.C
Capacitance Probe – Installation for a Water Tube Boiler
10.5.4.D
External Probe – Recommended Chamber Dimensions
